Micro/sys Announces Sub 1 Watt Pico-ITX SBC for Portable and Handheld Embedded Applications

Micro/sys has released a 2.5-inch Pico-ITX™ ARM single board computer offering power-through-USB and an impressive mix of video, audio, USB, memory, and power features for today’s handheld applications.

Featuring the cost-efficient, power-conscience Freescale Semiconductor i.MX515 ARM Cortex-A8 processor tailored for multimedia, the SBC5651 is ideally suited for use in small, low-power handheld and portable devices typical to medical, gaming, ticketing, and test and measurement applications.
