240W Power Supply with 150% Peak Load Output

Carlo Gavazzi is proud to announce the launch of a new and powerful switch-mode power supply in a compact housing. The SPD240C Series features a 150% peak load capability for a full 3 seconds and, at an installed width of only 64mm, this new series saves approximately 25% DIN-rail width compared with our standard 240 watt power supply. This enhanced 240 watt series also includes Active Power Factor Correction which improves the power factor to 0.97 @ 230VAC resulting in increasing the output power capability. Therefore, the SPD240C Series offers more power, using less panel space, thus making it an ideal choice for DC loads.

Additional standard features included with each SPD240C compact power supply are parallel function, universal AC input, enhanced CE certifications, a power ready relay output and short circuit protection. Technical features include:
  •     150% peak load capability
  •     Universal AC input 88-264VAC
  •     Active power factor correction
  •     Parallel connection
  •     Compact dimensions
  •     Power ready relay output
  •     LED for DC power low
  •     High efficiency to 83%
The compact SPD240C Series power supplies are UL and cUL listed, and TUV and CE approved, your assurance of high quality and safety.
