Siemens PLM Software's NX 8 Includes Comprehensive Enhancements Throughout with Focus on CAE

Siemens PLM Software, a business unit of the Siemens Industry Automation Division and a leading global provider of product lifecycle management (PLM) software and services, today announced the latest release of NX™ software, the company’s fully integrated computer-aided design, manufacturing and engineering analysis (CAD/CAM/CAE) solution. NX 8 includes extensive enhancements to its CAE offering – including its widely used NX Nastran® software for solving some of the world’s most challenging simulation problems. Today’s announcement further establishes NX CAE as one of the world’s leading simulation solutions for product development, while unveiling new capabilities throughout the NX design and manufacturing modules that build on Siemens PLM Software’s high-definition PLM (HD-PLM) vision and expand its digital manufacturing offerings for the machinery industry.

“NX 8 is a significant evolution of one of the world’s premier integrated digital product development systems,” said Jim Rusk, vice president, Product Engineering Software, Siemens PLM Software. “Our unsurpassed CAE solution has been further expanded to better enable users to identify and eliminate issues in the virtual world before they become problems in the real world. This ability to optimize product performance, combined with the extensive enhancements in NX design and manufacturing, will help our customers further reduce costs, shorten development time and facilitate smarter decisions that result in better products.”
