Siemens PLM Software Announces Latest Release of Femap for Enhanced Simulation in Product Development

Siemens PLM Software, a business unit of the Siemens Industry Automation Division and a leading global provider of product lifecycle management (PLM) software and services, today announced the latest release of Femap™ software, the world’s leading pre- and post-processor for engineering finite element analysis (FEA) running on the Windows® operating system. Enhancements in Femap 10.3 make it easier and significantly faster for end users to work with complex geometry models, and a new user interface feature further extends support for advanced functionality in NX™ NASTRAN® software, the company’s comprehensive FEA application.

“The ability to accurately simulate in a virtual environment how a product will perform in the real world can have a profound impact on the cost, quality, safety and customer satisfaction associated with that product,” said Bill McClure, vice president of product development for Velocity Series, Siemens PLM Software. “With the enhancements in Femap 10.3, we are continuing to increase the effectiveness of that simulation with tools that enable engineers to perform a more thorough and complete analysis on even the most complex geometry.”
